750-392
CBEX-DE
6-3
Burner Assembly 30 PPM/60 PPM/Uncontrolled Emissions
6.1.2 — Burner Assembly 500-800 HP (30-60PPM, 700 fuel series)
SECTION A-A
SECTION B-B
A
A
B
B
ITEM QTY PART NO DESCRIPTION
11
108-00134-000 DAMPER
2 1 868-00207-000
CAPSCREW
3 1 825-00030-000
COCK, GAS SERVICE
41
845-00194-000 ELBOW, MALE
5 8 860-00158-000
SET SCREW
6
1
048-00098-000 VENTURI, GAS PILOT
7 1 858-00310-000
PLUG, PIPE
8 1 090-01599-000 TUBE BURNER DRAWER
9
1
435-00129-000 ELECTRODE, IGNITION
10 1 853-00001-000 O-RING
11 1
034-00007-000 NUT, GLAND PACKING
12 1 868-00535-000
CAPSCRE
13 1 001-00197-000
ADAPTOR, GAS PILOT
14 1
904-00036-000 GROMET, RUBBER, CABLE
15 8 860-00090-000
MACH. SCREW
16
1
090-01597-000 PILOT TUBE ASSEMBLY
17 1 090-01600-000
TUBE, GAS PILOT
18
1 073-00041-000
SEAL RING, DAMPER
19
1
851-00077-000 MICA SHEET, SIGHT HOLE
ITEM QTY PART NO DESCRIPTION
20
1
065-00011-000 RETAINER, SIGHT HOLE
21 2 860-00201-000
SCREW, MACHINE
22 1 032-00497-000
GASKET, SCANNER TUBE
23
1
090-01596-000 GUIDE TUBE, SCANNER
24 1 134-00053-000
HOLDER, ELECTRODE
25
1
860-00244-000 SET SCREW, SOCKET HEAD
26 1 134-00050-000 SPIDER, DIFFUSER
27 1 SEE TABLE DIFFUSER, BURNER
28
1
073-00032-000 SEAL RING, GAS PILOT
29 1 022-00132-000 DIFFUSER - AIR STABILIZER, REAR
30
1
022-00133-000 DIFFUSER - AIR STABILIZER, FRONT
31 2 869-00021-000
NUT, HEX HD.
32 1 860-00088-000
MACH. SCREW
33
1
059-07073-000 BACKPLATE AND BEARING ASSEMBLY
34 5 860-00039-000
SETSCREW
35
1
158-00046-000 PLUG, BURNER DRAWER TUBE
36 1 860-00161-000
SET SCREW
37 3
860-00176-000 SCREW
W
, MACHINE
38 2 857-00740-000 NIPPLE, PIPE
201937
2
17
32
12
38
22
21
23
5
1610
1114
9
38
4
3
5 6
7
33
30 18
29
31
15
8
5
15 26
5
27
16 24
25
1
15 5
13 28
34
36
35
34
1
2
"
35
5
USAGE ITEM 27
500 HP 30PPM 275-02001-000
500 HP 60PPM 275-02715-000
600 HP 30PPM 275-00303-000
600 HP 60PPM 275-02716-000
700 HP 30-60PPM 275-00303-000
800 HP 30-60PPM 275-00304-000
