CleaverBrooks CBEX-DE User Manual

750-392
CBEX-DE
6-9
Modbus Actuators (parallel positioning)
6.5 — Modbus Actuators (parallel positioning)
6.5.1 — Air Actuator
VIEW A-A
SECTION C-C
B
B
DESCRIPTIONPART NO.QTYITEM
BRACKET, AIR ACTUATOR, GEAR DRIVE008-04250-000
11
GEAR, SPUR033-00137-000
1
2
GEAR,SPUR
SEE TABLE13
SPACER, AIR DAMPER GEAR ASSEMBLYSEE TABLE14
CONNECTOR, AIR DAMPER845-03381-00015
SETSCREW860-00039-000
7
6
CAPSCREW868-00150-0002
7
CAPSCREW868-01369-000
4
8
ACTUATOR,SEE TABLE19
LOCK WASHER
952-00097-000210
LOCKWASHER952-00471-000411
WASHER
952-00133-000212
GUARD, SAFETY
450-00068-000
1
13
WASHER952-00145-0002
14
SCREW, SELF TAPPING841-00148-0002
15
KEY, SQUARE DRIVE841-00739
1
16
4 1/2
CENTER DIST.
"A"
DAMPER FULL OPEN
26
3 6
7
10 12
5
6
WITH QUICK DISCONNECTS WITHOUT QUICK DISCONNECTS
MODEL A B ITEM #3 ITEM #4
269-00156-0QC
269-00156-000
250-400 HP
43° 4.3° 033-00125-000 077-02123-000
269-00157-0QC
269-00157-000
500-600 HP
45° 6.8° 033-00126-000 077-02124-000
269-00461-0QC
269-00461-000 700-800 HP 45° 6.8° 033-00127-000 077-00597-000
1
"B"*
3
4
13
1514
NOTES:
1) DIMENSIONS "A" AND "B" ARE FOR REFERENCE ONLY.
2) ENSURE GEAR TEETH ARE FULLY ENGAGED THROUGHOUT
THE ENTIRE AIR DAMPER OPERATIONAL ROTATION RANGE.
3) CONNECTOR TO BE INSTALLED WITH 1/16" CLEARANCE
FROM ACTUATOR.
16
6
5
2
8 11
9
ITEM #9
WITH QUICK DISCONNECTS WITHOUT QUICK DISCONNECTS
945-00260-000 945-00376-000
6
