CleaverBrooks CBEX-DE User Manual

Parts
6-10
750-392
CBEX-DE
6.5.2 — FGR Actuator
6.5.3 — Gas Actuator
DESCRIPTIONPART NO.QTYITEM
BRACKET, FGR ACTUATOR 008-04062-000
11
COUPLING, FLEX, ALUMINUM
819-00389-00012
CAPSCREW
868-00136-00023
CAPSCREW868-00209-0002
4
ACTUATORSEE TABLE15
WASHER952-00092-00026
LOCK WASHER952-00117-00027
WASHER
952-00144-00028
WASHER, FLAT952-00145-00029
WARNING LABELSEE TABLE110
EXISTING FGR DAMPER SHAFT
WITH INDICATOR ARM
REFERENCE
FRONT HEAD
1
8
74
396
2
5
ASSEMBLY WIRING CONNECTION ITEM #5 ITEM #10
269-00151-000 CONDUIT WIRED 945-00375-000
-
269-00151-0QC QUICK DISCONNECT
945-00259-000
-
269-00151-AFT*
CONDUIT WIRED 945-00375-000 118-04712-000
269-00151-CON
QUICK DISCONNECT
945-00259-000 118-04712-000
REMOVAL OF ACTUATOR
WILL REQUIRE
COMBUSTION
TO BE RESET
LE REMPLACEMENT DE
L’ACTUATEUR VA
NÉCESSITER UN
RÉAJUSTEMENT DE LA
COMBUSTION
118-04712-000
DESCRIPTIONPART NO.QTYITEM
BRACKETSEE TABLE
11
CONNECTORSEE TABLE12
SETSCREW
860-00039-00043
ACTUATORSEE TABLE
14
CAPSCREW
868-00209-00025
LOCK WASHER952-00117-00026
WASHER
952-00144-00027
1
2
3
4
REMOVE FOOT SUPPLIED
W/ GAS VALVE AND
USE SCREWS
GAS VALVE
ASSY WITH QUICK DISCONNECTS ASSY WITHOUT QUICK DISCONNECTS
USED ON ITEM #1 ITEM #2
269-00242-0QC
269-00242-000
1-1/2" VALVE
008-03558-000 845-01152-000
269-00152-0QC
269-00152-000
2" VALVE
008-03570-000 845-01152-000
269-00158-0QC
269-00158-000
2-1/2"-3" VALVE
008-03529-000 845-01082-000
269-00159-0QC
269-00159-000
4" VALVE
008-03522-000 845-01082-000
567
ITEM #4
ASSY WITH QUICK DISCONNECTS ASSY WITHOUT QUICK DISCONNECTS
945-00259-000 945-00375-000
