Parts
6-12
750-392
CBEX-DE
6.6 — Gas Train
A typical gas train is shown below; configurations may vary. Gas train component selection is based on boiler HP,
emissions level, piping and connection sizes, pressure requirements, and insurance. Contact Cleaver-Brooks
Aftermarket for information regarding your specific application.
VPS or VENT VALVE
ASSEMBLY
DOWN STREAM
ASSEMBLY
TRANSITION ASSEMBLY
SSOV
ASSY.
LGPS
ASSY.
HGPS
ASSY.
PILOT GAS TRAIN ELBOW ASSEMBLY
PILOT GAS TRAIN ASSEMBLY
PILOT TUBING
ASSEMBLY
MANIFOLD PRESSURE
GAUGE ASSEMBLY
STARTER
TRAIN
ASSEMBLY
