750-392
CBEX-DE
1-1
CHAPTER 1 Introduction
1.1 — Overview
The CBEX-DE boiler is a packaged firetube boiler of welded steel construction and consists of a pressure vessel,
burner, burner controls, forced draft fan, air compressor for oil atomization, oil pump, refractory, and boiler trim
supplied according to customer’s request.
Like all CBEX boilers, the CBEX-DE features spiral tubes for enhanced heat transfer. Other features include:
• 30 ppm NOx standard
• Hinged or davited insulated rear door with sight port
FIGURE 1-1. CBEX-DE cutaway view
