19
Child MUST meet ALL of the following
requirements to use this car seat:
√ Child weighs between 4 and 35 lb (1.8 and 15.9 kg).
√ Child’s height is 32 in. (81.3 cm) or less.
√ The top of the child’s head is at least 1 in. (2.5 cm)
below the top of the Carrier Seat Back, as shown in
Figure 1.
√ Shoulder Harness Straps MUST be through Shoulder
Harness Slots at or below and closest to child’s
shoulders, as shown in Figure 2.
√ Newborn Support System MUST be used with infants
11 lb (5 kg) or less and if top of shoulders are below
lowest Shoulder Harness Slots.
Min.
1 in.
(2.5 cm)
Figure 1
Figure 2
