28
Shoulder Harness Cover
Removal/Installation
Use of the Shoulder Harness Covers included with this
seat is optional.
To Install: Position Shoulder Harness Covers around
Shoulder Harness Straps with snaps facing away
from child’s neck and fasten the snaps together to
close as shown in Figure 12.
To Remove: Unfasten the snaps on the Shoulder Harness
Covers and remove Shoulder Harness Covers.
IMPORTANT: Remove Shoulder Harness Covers if they
prevent the Chest Clip from being properly positioned
at armpit level or if you are unable to achieve a snug
Harness.
Figure 12
