75
Figure 71
Figure 70
1
2
3
Step 3
Open Belt Tensioner as shown in Figure 70:
• One hand: Press down on the front panel of the Belt
Tensioner and hold (1).
• Other hand: Squeeze the Belt Tensioner Release
Handle to unlock Belt Tensioner (2).
• Rotate Belt Tensioner into the fully open position by
rotating toward front of vehicle (3).
Step 4
Remove vehicle belt from blue Vehicle Belt Guides, as
shown in Figure 71.
To Next Page
