Car Seat Features – Base
26 Vehicle Belt Guides
27 Belt Tensioner
28 Belt Tensioner Release Handle
29 Belt Tensioner Lock Indicators
30 Recline Sled Adjustment Handle
31 Recline Indicator
32 LATCH Adjustment Buttons
33 LATCH Connectors
34 LATCH Lock Indicators
35 LATCH Release Buttons
36 Carrier Lock Tab
37 Release Handle
(to release Carrier from Base)
38 Load Leg
39 Load Leg Adjustment Handle
40 Load Leg Pressure Indicator
41 Load Leg Storage
42 Instruction Manual Storage Slot
43 Recline Sled
41
27
26
26
43
38
40
42
Liing Instruction Manu al
WARNING
• Read and understand all
information and instructions on
product labels and in this manual
and in your vehicle owner’s
manual before installing or using
this car seat/infant carrier.
• Failure to properly install or
use this car seat or follow the
warnings in this manual and on
the car seat’s labels can result
in serious injury or death to the
child in a sharp turn, sudden
stop or crash.
E01-2533-A1-CA
January 2019
LI19CAA1
HEIGHT WEIGHT
81.3 cm (or less)
32 in. (or less)
1.8-15.9 kg
4–35 lb
Keep instructions for future use.
Store in the Instruction Manual Storage Slot in
Car Seat Base.
11-20 lb
20-35 lb
4-11 lb
9.1-
15.9 kg
5-9.1 kg
1.8-5 kg
Adjust recline so bubble is between
2 lines designated for child's weight
Ajuste la reclinación de manera que la burbuja quede
entre 2 líneas designadas para el peso del niño
31
33
34
35
