Tranquility
®
Digital (DXM2)—Troubleshooting Guide
Rev.: 10 March, 2015
32
Geothermal Heating and Cooling
Replacing Variable-Speed Pump Power Head
A-P
1) You can remove power head from motor with # 25 Torx driver if feedback is out of range.
2) Remove plastic cover to remove Torx head screws.
Comp verify voltage
197-254V
Verifying Power at Molded Plug For Compressor
A-Q
