Digital (DXM2)—Troubleshooting Guide
Rev.: 10 March, 2015
48
Geothermal Heating and Cooling
Electrical—Power Wiring
B-M
Electrical—Power Wiring
B-N
Remove Harness Plug
Note: For 115v power only. Damage will occur to motor
with 230v power supply if 115v jumper is used.
Install Two Pin Jumper Plug
Note: Check the unit voltage with the harness connected and unit powered up.
DXM2AXM
9-15V DC
9-15V DC
To Next Page
