Tranquility
®
Digital (DXM2)—Troubleshooting Guide
Rev.: 10 March, 2015
54
Geothermal Heating and Cooling
Fan Connections
Electric Heat
Connections
9-wire connection to non-
communicating thermostat/
compressor section
4-wire connection to
communicating thermostat
4-wire
connection
to DXM2
Accessory
outputs
that track
blower
operation
LT2
Sensor
Condensate
Sensor
AXM Board Layout and Dipswitches
