CLIVET TALK User Manual

Data creazione 10/09/03 DS03I009GB--00 Pagina 43 di 59
COMPRESSOR MODULE ALARMS
Code displayed Reset Description-actions
E101 Cond./ Evap. temp. probe fault Automatic TypeCE=0; Cooling: signal only, Heating:
stop circuit in question (see example)
E102 Condensing pressure probe fault Automatic Stop circuit in question (see example)
E103 Evaporation pressure probe fault Automatic Stop circuit in question (see example)
E104 Recovery temp. probe fault Automatic Disable "compressor module 4-way valve"
output (inhibit recovery)
E105 High pressure alarm Manual Stop circuit in question (see example)
E106 Low pressure alarm Automatic Stop circuit in question (see example)
E107 Fan thermal cut-out alarm Manual Stop circuit in question (see example) If the
ventilation is in common, shut-down “UNIT-
i"
E111 Cond. / Evap. H2O flow alarm Automatic TypeCE=1; Stop circuit in question (see
example)
E112 High pressure pre-alarm 1 Automatic (*) HP1Enabled=0: alarm not managed
HP1Enabled=1: activate maximum speed of
fans in question (see example)
E113 High pressure pre-alarm 2 Automatic (*) HP2Enabled=0: alarm not managed
HP2Enabled=1: disable one compressor in
the circuit in question (see example)
E114 Low pressure pre-alarm Automatic - Manual
after NPRELP1hour
(*)
LP1Enabled=0: alarm not managed
LP1Enabled=1 disable one compressor in
the circuit in question (see example)
E115 Force defrost alarm Automatic (*) Signal only
E116 Max Press. diff. alarm Manual Stop circuit in question (see example)
E117 Recovery H2O flow alarm Automatic Stop circuit in question (see example)
E118 Heat recovery HP pre-alarm Automatic - Manual
after NPREHPhour
(*)
Inhibit recovery on the circuit in question
(see example)
E108 Compressor 1 thermal cut-out
alarm
Manual Stop circuit in question (see example)
E109 Compressor 2 thermal cut-out
alarm
Manual Stop circuit in question (see example)
E110 Compressor 3 thermal cut-out
alarm
Manual Stop circuit in question (see example)
E213 Disconnected module Automatic Total shut-down
NOTE
The compressor module alarms have the same identifier on each compressor module in the system.
Consequently, to correctly identify which module the fault refers to, see the associated code:
Example:
U2-CMP2 (Alarm Unit-2 / Compressor Module 2)
E105 High pressure alarm
Indicates that the alarm condition is active on Compressor Module 2, Unit 2
