40 WDAT-SL3 FC 200.2-580.2 M08S40E15-01
code description detailed description
AI-965 T.OutH2ORec_X3 Recovery outlet water temperature
AI-965 T.OutGasRec_X1 Recovery gas outlet temperature (liquid)
AO-965 %CmdPmpRec_X8 % 0-10vcc signal value recovery variable pump
DI-965 EnableRec_X4 Enabling recosvery input: 0=Fault 1=OK
DI-965 Ovl PmpRec_X5 Recovey thermal protection pump 0=Fault 1=OK
DI-965 FlowRec_X6 Flow recovery 0=Fault 1=OK
DI-965
SystemPress.Recov-
ery_DL1
State of the water pressure switch contact of the system 0=Fault 1=OK
DO-965 YV1Rec_DO1 Command valve YV1 0=O 1=On
DO-965 YV2Rec_DO2 Command valve YV2 0=O 1=On
DO-965 YV3Rec_Q1 Command valve YV3 0=O 1=On
DO-965 YV4Rec_Q2 Command valve YV4 0=O 1=On
DO-965 YV5Rec_Q3 Command valve YV5 0=O 1=On
DO-965 PmpRec_Q4 Recovery pump command 0=O 1=On
9.5 Master slave status
code description detailed description
S0600 SetPoint Unit1
Value accessible from the display of the unit machine network master.
Working setpoint master unit (Address 1 on periferalbus)
S0601 SetPoint Unit2
Value accessible from the display of the unit machine network master.
Working setpoint unit 2 (Address 2 on periferalbus)
S0602 SetPoint Unit3
Value accessible from the display of the unit machine network master.
Working setpoint unit 3 (Address 3 on periferalbus)
S0603 SetPoint Unit4
Value accessible from the display of the unit machine network master.
Working setpoint unit 4 (Address 4 on periferalbus)
S0604 SetPoint Unit5
Value accessible from the display of the unit machine network master.
Working setpoint unit 5 (Address 5 on periferalbus)
S0605 SetPoint Unit6
Value accessible from the display of the unit machine network master.
Working setpoint unit 6 (Address 6 on periferalbus)
S0606 SetPoint Unit7
Value accessible from the display of the unit machine network master.
Working setpoint unit 7 (Address 7 on periferalbus)
S0607 statusUnit1
Value accessible from the display of the unit machine network master.
Status master unit 7 0=O 1=Eco 2=On 3=PmpOn
S0608 StatusUnit2
Value accessible from the display of the unit machine network master.
Status unit 2 0=O 1=Eco 2=On 3=PmpOn
S0609 StatusUnit3
Value accessible from the display of the unit machine network master.
Status unit 3 0=O 1=Eco 2=On 3=PmpOn
S0610 StatusUnit4
Value accessible from the display of the unit machine network master.
Status unit 4 0=O 1=Eco 2=On 3=PmpOn
S0611 StatusUnit5
Value accessible from the display of the unit machine network master.
Status unit 5 0=O 1=Eco 2=On 3=PmpOn
S0612 StatusUnit6
Value accessible from the display of the unit machine network master.
Status unit 6 0=O 1=Eco 2=On 3=PmpOn
S0613 StatusUnit7
Value accessible from the display of the unit machine network master.
Status unit 7 0=O 1=Eco 2=On 3=PmpOn
9.6 Hydronic module status
code description detailed description
AO-965 %CmdInverter_X7 % value inverter command signal
DI-965 OvlP1.Hid_X4 Pump 1 overload 1: 0=OK 1=Fault
DI-965 OvlP2.Hid_X5 Pump 2 overload: 0=OK 1=Fault
DI-965 OvlP3.Hid_X6 Pump 3 overload: 0=OK 1=Fault
DI-965 OvlInv.Hid_DL1 Inverter overload: 0=OK 1=Fault
DO-965 CmdP1.Hid_DO1 Pump 1 command: 0=O 1=On
DO-965 CmdP1Inv.Hid_Q2 Pump 1 inverter command: 0=O 1=On
DO-965 CmdP2.Hid_DO2 Pump 2 command: 0=O 1=On
DO-965 CmdP2Inv.Hid_Q3 Pump 2 inverter command: 0=O 1=On
