CLIVET WDAT-SL3 FC Series User Manual

FCD / FCI CONFIGURATION
Acoustic conguration: compressor soundproong (SC)
General technical data - Performance
Size 200.2 210.2 220.2 240.2 260.2 280.2 320.2 340.2 360.2 400.2 440.2 500.2 540.2 580.2
Cooling
Cooling capacity 1 [kW] 469 503 527 567 622 675 752 814 868 942 1058 1183 1272 1375
Compressor power input 1 [kW] 137 148 154 166 185 199 223 238 259 284 323 349 384 417
Total power input 2 [kW] 150 162 170 182 202 218 243 261 281 309 349 380 416 450
Partial recovery heating capacity 3 [kW] 91 98 102 110 121 131 146 158 169 184 207 230 248 269
EER 1 - 3,12 3,11 3,11 3,12 3,09 3,10 3,09 3,12 3,08 3,05 3,03 3,11 3,06 3,06
Water ow-rate (User Side) 1 [l/s] 22,4 24,0 25,2 27,1 29,7 32,3 35,9 38,9 41,5 45,0 50,6 56,5 60,8 65,7
Total pressure drop user side - FCD 1 [kPa] 62,1 70,4 54,9 63,5 74,3 62,8 75,8 86,5 94,4 29,7 37,7 64,6 72,3
81,2
Total pressure drop user side - FCI 1 [kPa] 81,5 92,6 73,8 85,4 102 87,7 107 92,5 103 67,8 85,9 125 142 162
Cooling capacity (EN14511:2013) 4 [kW] 467 500 525 564 619 672 748 809 862 940 1056 1178 1266 1369
Total power input (EN14511:2013) 4 [kW] 152 164 172 184 205 221 247 265 287 311 351 385 421 456
EER (EN 14511:2013) 4 - 3,06 3,05 3,05 3,06 3,02 3,04 3,03 3,05 3,01 3,02 3,01 3,06 3,01 3,00
ESEER 4 - 3,89 3,89 3,89 3,91 3,85 3,87 3,91 3,89 3,89 3,87 3,85 3,88 3,85 3,89
Cooling capacity (AHRI 550/590) 5 [kW] 466 499 523 562 618 670 746 805 856 935 1048 1174 1263 1365
Total power input (AHRI 550/590) 5 [kW] 150 161 169 181 201 217 242 259 279 308 348 380 414 448
COPR 5 - 3,11 3,10 3,10 3,10 3,08 3,08 3,08 3,10 3,06 3,03 3,01
3,09 3,05 3,05
IPLV 5 - 4,36 4,34 4,35 4,36 4,30 4,33 4,38 4,35 4,36 4,32 4,32 4,35 4,31 4,38
1. Data referred to the following conditions: internal exchanger water = 12/7 °C. Entering external exchanger air
temperature 35°C. Evaporator fouling factor = 0.44 x 10^(-4) m2 K/W
2. The Total Power Input value does not take into account the part related to the pumps and required to overcome
the pressure drops for the circulation of the solution inside the exchangers
3. Recovery exchanger water=40/45°C
4. Data compliant to Standard EN 14511:2013 referred to the following conditions: - Internal exchanger water
temperature = 12/7°C - Entering external exchanger air temperature = 35°C
5. Data compliant to Standard AHRI 550/590 referred to the following conditions: internal exchanger water
temperature = 6,7 °C. Water ow-rate 0,043 l/s per kW. Entering external exchanger air temperature 35°C.
Evaporator fouling factor = 0.18 x 10^(-4) m
2
K/W
Acoustic conguration: super-silenced (EN)
General technical data - Performance
Size 200.2 210.2 220.2 240.2 260.2 280.2 320.2 340.2 360.2 400.2 440.2 500.2
Cooling
Cooling capacity 1 [kW] 464 496 521 565 616 672 737 810 850 935 1030 1166
Compressor power input 1 [kW] 143 150 161 168 189 207 221 247 263 283 320 363
Total power input 2 [kW] 148 155 166 174 194 214 229 255 271 292 329 372
Partial recovery heating capacity 3 [kW] 91 97 102 110 121 132 144 159 167 183 203 229
EER 1 - 3,13 3,21 3,14 3,25 3,17 3,14 3,23 3,18 3,14 3,21 3,13 3,14
Water ow-rate (User Side) 1 [l/s] 22 24 25 27 29 32 35 39 41 45 49 56
Total pressure drop user side - FCD 1 [kPa] 51,1 58,3 53,7 63,4 73,5 62,1 73,5 86,2 91,5 29,6 36,2 63,1
Total pressure drop user side - FCI 1 [kPa] 69,7 79,5 72,3 84,7 100 86,9 103 91,7 99,6 66,7 81,5 121
Cooling capacity (EN14511:2013) 4 [kW] 462 494 519 562 613 669 733 805 845 933 1028 1162
Total power input (EN14511:2013) 4 [kW] 150 157 168 176 197 216 232 259 276 293 332 376
EER (EN 14511:2013) 4 - 3,08 3,15 3,09 3,19 3,10 3,09 3,16 3,11 3,06 3,18 3,10 3,09
ESEER 4 - 4,16 4,24 4,18 4,23 4,19 4,20 4,24 4,20 4,16 4,24 4,19 4,19
Cooling capacity (AHRI 550/590) 5 [kW] 461 492 517 560 612 666 731 801 838 927 1021 1158
Total power input (AHRI 550/590) 5 [kW] 148 154 165 173 194 213 228 254 269 291 328 371
COPR 5 - 3,13 3,19 3,13 3,23 3,16 3,13 3,21 3,16 3,12 3,19 3,11 3,12
IPLV 5 - 4,65 4,73 4,67 4,72 4,68 4,69 4,75 4,69 4,67 4,74 4,71 4,70
1. Data referred to the following conditions: internal exchanger water = 12/7 °C. Entering external exchanger air
temperature 35°C. Evaporator fouling factor = 0.44 x 10^(-4) m2 K/W
2. The Total Power Input value does not take into account the part related to the pumps and required to overcome
the pressure drops for the circulation of the solution inside the exchangers
3. Recovery exchanger water=40/45°C
4. Data compliant to Standard EN 14511:2013 referred to the following conditions: - Internal exchanger water
temperature = 12/7°C - Entering external exchanger air temperature = 35°C
5. Data compliant to Standard AHRI 550/590 referred to the following conditions: internal exchanger water
temperature = 6,7 °C. Water ow-rate 0,043 l/s per kW. Entering external exchanger air temperature 35°C.
Evaporator fouling factor = 0.18 x 10^(-4) m
2
K/W

