8. Configuration
8. 4 Limit comparators” LC”
In the case of the limit comparator functions lk7 and lk8, the measurement that is set
is monitored with respect to a fixed value AL.
Hysteresis function
asymmetrical, left
symmetrical
asymmetrical, right
lk7
lk8
Limit comparator 1 LC1 ➔
Limit comparator 2 LC2 ➔
Limit comparator 3 LC3 ➔
Limit comparator 4 LC4 ➔
Function
Limit value
Switching
differential
Symbol
Value/selection
Description
Fnct
0
1
2
3
4
5
6
7
8
no function
lk1
lk2
lk3
lk4
lk5
lk6
lk7
lk8
AL
-1999… 0…+9999
Limit value to be monitored.
Limit range for lk1 and lk2: 0 — 9999
HySt
0…1…9999
Switching differential
