Compact controller ER 2022S and ER 2022SA
www.clori uscontrols.com
51 of 69
8. Configuration
8.9 Interface “intE”
intE: Interface
The interface parameters for the RS422/485 or Profibus-DP
interface have to be configured in order to communicate with PCs,
bus systems and peripheral devices.
PROFIBUS-DP Pr0F ➔
Symbol Value/selection Description
Protocol
Prot
0
1
2
Motorola
Intel
Intel integer
Device address
Adr
0…125 …255 Address in data network
Analog marker
AnAP
-1999… 0 …+9999 Analog value
Binary marker
binP
0 …255 Binary value
NOTE: Factory settings are shown in BOLD
PR Modbus
r422 ➔
Symbol Value/selection Description
Protocol Prot
0
1
Modbus
Modbus integer
Baud rate bdrt
0
1
2
9600 bps
19200 bps
38400 bps
Data format
dFt
0
1
2
3
8 data bits, 1 stop bit, no parity
8 data bits, 1 stop bit, odd parity 8
data bits, 1 stop bit, even parity 8
data bits, 2 stop bit, no parity
Device
address
Adr 0…1 …255 Address in data network
Min. response
time
(setup) 0…500ms Minimum time that elapses between the request of a
device in the data network and the response of the
controller.
NOTE: Factory settings are shown in BOLD
H
Interface description B70.3041.2
Configuration
Analog inputs
Controller
Generator
Limit comparators
Outputs
Binary functions
Display
Timer
Interfaces
