8. Configuration
8.7 Display “diSP”
diSP: Display
The values displayed can be matched to the existing requirements.
Furthermore, time-out and level inhibit can be configured here
Symbol Value/selection Description
Upper display d iSU (analog selector)
controller process
value
Displayed value for the upper display
Lower display
d iSL
(analog selector)
controller set point
Displayed value for the lower display
Decimal point
dEcP 0
1
2
no decimal place
one decimal place
two decimal places
If the value is be displayed can no longer be
represented with the programmed decimal point, then
the number of decimal places will automatically
reduce. If subsequently the measured value decreases
the number increases to the programmed value of the
decimal point,
Brightness
br iG 0…5 (bright) 0—5 (dark)
16-segment
display
(set up)
switched off
Unit
current segment
current parameter
set
text
Displayed value for the two-digit 16-segment display
Timeout (set up) 0…180…255s Time period, after which the instrument automatically
returns to normal display if no key is pressed.
Level inhibit (set up) None
configuration level
parameter/
configuration level
operator/
parameter/
configuration level
The access to the individual levels can be inhibited.
The setting is independent of the binary function
“level inhibit.”
Inhibiting the parameter level will, at the same time,
also inhibit the start of autotuning.
User data (setup program)
Up to eight parameters from various levels can be shown under User data (operator level)
on the instrument and edited. The symbols for these parameters (shown in the lower
display) must be assigned by the user himself.
NOTE: Factory settings shown with BOLD text
