Compact controller ER 2022S and ER 2022SA
www.clori uscontrols.com
49 of 69
8. Configuration
8.7 Display “diSP”
0 no function
1 analog input 1
2 analog input 2
3 process value
4 present set point
5 ramp end value
6 program set point
7 math 1
8 math 2
9 set point 1
10 set point 2
11 set point 3
12 set point 4
13 controller output level
14 controller output 1
15 controller output 2
21 program run time in sec
22 residual program time in sec
23 segment run time in sec
24 residual time in sec
25 timer run timer 1 in sec
26 timer run rimer 2 in sec
27 residual run time for timer 1 in sec
28 residual run time for timer 2 in sec
29 present segment end value
30 analog marker (Profibus)
31 reserved
32 reserved
33 reserved
Analog selector
