Clorius Controls ER 2022S - Page 43

Compact controller ER 2022S and ER 2022SA
www.clori uscontrols.com
43 of 69
8. Configuration
8.5 Outputs “OutP”
Standard for all instrument versions:
(Binary) output 1 (Out1) = relay (Binary)
output 2 (Out2) = relay (Binary) output 3
(Out3) = logic output (Binary) output 4
(Out4) = logic output
Extended numbering for the option slots:
Slot Plug-in board with
1 analog output
Plug-in board with
1 binary output
(relay or solid- state relay)
Plug-in board with
1 binary output
(2 relays)
Option 1
Output 5 (Out5)
Output 5 (Out5)
Output 5+8 (out5/Out8)
Option 2
Output 6 (Out6)
Output 6 (Out6)
Output 6+9 (out6/Out9)
Option 3
Output 7 (Out7)
Output 7 (Out7)
Output 7+10 (out7/Out10)
Symbol
Value/selection
Description
Binary
output 1
0ut1
0
no function
….
1
Controller output 1 (ex-factory with Out1)
2
Controller output 2
5
Binary input 1
6
Binary input 2
7
Binary input 3
8
Binary input 4
9
Binary input 5
10
Binary input 6
11
Binary input 7
12
Binary input 8
13
Limit comparator 1
Binary
0ut0
14
Limit comparator 2
Output 10
15
Limit comparator 3
16
Limit comparator 4
17
Control contact 1
18
Control contact 2
19
Control contact 3
20
Control contact 4
21
Logic formula 1
22
Logic formula 2
23
Timer 1 active
24
Timer 2 active
25
Program active
26
Program end signal
27
Tolerance limit signal
29
Manual mode on/off
29
Binary marker
30
Any binary value from storage address (only through setup)
31
Always active
NOTE: Factory settings shown with BOLD text
OutP: Outputs
Configuration of the instrument outputs are subdivided into analog outputs
(OutA; max. 2) and binary outputs (OutL; max. 9). Binary outputs are relay,
solid-state relay and logic outputs. Display and numbering of the outputs
depends on the assignment of the option slots.
The switching states of the binary outputs 1— 6 are shown in the display.
Configuration
Analog inputs
Controller
Generator
Limit comparators
Outputs
Binary functions
Display
Timer
Interfaces
Numbering of the
outputs
