CM Shopstar - Page 29

29
P/N 192047138 Rev AA November 2017
SHOPSTAR PARTS LIST
ITEM
NO.
PART
NUMBER
DESCRIPTION QTY.
1 20704 LIFTWHEEL SHAFT SEAL 1
2 20723 BRAKE SPACER 1
3
BRAKE END COVER
20323 BRAKE END COVER - ORANGE 1
20377 BRAKE END COVER - WHITE 1
20366 BRAKE END COVER - YELLOW 1
4 20313 LIFTWHEEL SHAFT 1
5
MOTOR END COVER
20302 MOTOR END COVER - ORANGE 1
20356 MOTOR END COVER - WHITE 1
20369 MOTOR END COVER - YELLOW 1
6
GEAR HOUSING
20350 GEAR HOUSING - ORANGE 1
20371 GEAR HOUSING -WHITE 1
20368 GEAR HOUSING - YELLOW 1
7
MAIN FRAME
20352 MAIN FRAME - ORANGE 1
20370 MAIN FRAME - WHITE 1
20367 MAIN FRAME - YELLOW 1
8 20419 BRAKE BASE PLATE 1
9 20651 ROTOR ASSEMBLY 1
10 20698 BRAKE DISC 1
11 20700 PIN RETAINER PLATE 1
12 20727 ROTOR THRUST WASHER 1
13 20729 CHAIN GUIDE/STRIPPER PIN 4
14 20743 PIN RETAINER PLATE SCREW 2
15 20755 GASKET 1
16 20758 CAUTION LABEL 1
17 24842 WARNING LABEL 2
18 88638 LIFTWHEEL THRUST WASHER 2
19 88639 FIRST PINION THRUST WASHER 2
20 88640 PROTECTOR THRUST WASHER 2
21 920718 GEAR HOUSING SCREW 4
22 920719 MOTOR COVER SCREW 3
23 920720 DOWEL PIN 4
24 920756 WIRE NUT *
25 10001215 BRAKE SCREW 4
26
CAPACITY WARNING LABEL
20762 CAPACITY WARNING LABEL - 250 lbs. 1
20737 CAPACITY WARNING LABEL - 300 lbs. 1
20763 CAPACITY WARNING LABEL - 500 lbs. 1
20738 CAPACITY WARNING LABEL - 600 lbs. 1
20884 CAPACITY WARNING LABEL - 1,000 lbs. 1
27
CHAIN GUIDE/STRIPPER
10001230 SINGLE PIECE CHAIN GUIDE/STRIPPER 1
20304/
20305
INDIVIDUAL CHAIN GUIDE/STRIPPER 1
ITEM
NO.
PART
NUMBER
DESCRIPTION QTY.
28
HOIST LABEL
20753 SERIES LABEL (SHOPSTAR) 1
20874 SERIES LABEL (SHOPHOIST) 1
20901 SERIES LABEL (SLC) 1
20903 SERIES LABEL (SLM) 1
29 20887 BRAKE SPRING 1
30 20422 FIRST PINION & DRIVE SHAFT 1
31
LIFTWHEEL AND GEAR ASSEMBLY
20666 LIFTWHEEL AND GEAR ASSEMBLY - 6 fpm, 1,000 lbs. 1
20664
LIFTWHEEL AND GEAR ASSEMBLY - 8 fpm, 500,
600 & 1,000 lbs.
1
20666 LIFTWHEEL AND GEAR ASSEMBLY - 12 fpm, 500 lbs. 1
20647
LIFTWHEEL AND GEAR ASSEMBLY - 12 fpm, 600
& 1000 lbs.
1
20664
LIFTWHEEL AND GEAR ASSEMBLY - 16 fpm, 250,
300 & 500 lbs.
1
20657
LIFTWHEEL AND GEAR ASSEMBLY - 20 fpm, 500
& 600 lbs.
1
20647
LIFTWHEEL AND GEAR ASSEMBLY - 24 fpm, 250,
300 & 500 lbs.
1
20657
LIFTWHEEL AND GEAR ASSEMBLY - 40 fpm, 250
& 300 lbs.
1
32 20420 BRAKE ARMATURE 1
33
STATOR
20707 STATOR - 115-1-50/60 HOISTS 1
20328 STATOR - 220-1-50 HOISTS 1
20329 STATOR - 220-3-50/60 HOISTS 1
20330
STATOR - 380-3-50, 415-3-50 & 460-3-60
HOISTS
1
20344 STATOR - 575-3-60 HOISTS 1
192039309 STATOR - 220/230-3-50/60 WITH PCB 1
192039311 STATOR 380-3-50, 400-3-50, 415-3-50 WITH PCB 1
34
BRAKE FIELD (INCLUDES BRAKE COIL)
20659
BRAKE FIELD (INCLUDES BRAKE COIL) -
115-1-50/60 HOISTS
1
20658
BRAKE FIELD (INCLUDES BRAKE COIL) -
220-1-50, 220-3-50/60, 380-3-50, 415-3-50 &
460-3-60 HOISTS
1
20629
BRAKE FIELD (INCLUDES BRAKE COIL) - 575-3-60
HOISTS
1
192039344 BRAKE FIELD - PCB 1
35
BRAKE END COVER SCREW
920715
BRAKE END COVER SCREW - HOISTS WITHOUT
CONTACTOR
3
20808
BRAKE END COVER SCREW - HOISTS WITH
CONTACTOR
3
36
CUT-OUT DEVICE
20709 CUT-OUT DEVICE - 115-1-50/60 HOISTS 1
20786 CUT-OUT DEVICE - 220-1-50, 230-1-60 HOISTS 1
37
CAPACITOR
20708 CAPACITOR - 115-1-50/60 HOIST 1
20785 CAPACITOR - 220-1-50 HOIST 1
38 20714 DEAD END PLATE (DOUBLE CHAINED) 1
