MAN.234 Rev.6 ENG - Use and maintenance manual S19HD page 22 of 126
3.1.3 Other power supplies *optional
The machine can be supplied on request completely
with a 48 V electric engine powered by 160 Ah lithi-
um batteries or with a hybrid feed.
It is not possible to have the 48 V electric
engine and the 110/120/230 V one activat-
ed on the machine at the same time.
It is not possible to turn on both the en-
dothermic engine and the electric engine
at the same time.
The start and stop of the 48 V electric engine will be
the same shown above for 110/120/230 V electric
engine.
To recharge the batteries:
1. couple the 110/120/230 V socket (power line)
to the plug on the machine and move upward
the button provided on the machine's thermal
magnetic panel;
2. from this moment the batteries will be charging
and, if the electric system is ON, the progress
of the charging process will be shown on the
control station LED panel (Picture 9).
When the state of batteries charge, dur-
ing the use, reaches the lowest level (un-
der 10%), all work maneuvers will be in-
terrupted, and it will only be possible to
close the machine again.
It is absolutely forbidden to direct high-
pressure jets of water onto the support
containing the battery pack. High water
pressure could generate serious and irre-
versible problems in the operation of the
machine.
3.2 Platform control stations
There are the following platform control stations:
1. the first one (operating) is the AUTEC radio
control station (Picture 8);
2. the second one (operating) is the AUTEC
wired remote control station in the basket;
3. the third one (emergency) is totally hydraulic,
with electrovalves distributor and outriggers
levers, and it is located on the frame.
