MAN.234 Rev.6 ENG - Use and maintenance manual S19HD page 36 of 126
WARNING! In both cases, it is advisable
to remove the basket to reduce encum-
brances and favor the operations.
Always use the radio control for load-
ing/unloading operations.
4.3.1 Loading/unloading through ramp
Check that no one is in proximity and
that the MEWP is in transport configura-
tion.
The tracks should be extended to maximum
width for improved stability and increased
ground clearance (*optional) when loading
and unloading the MEWP using ramps, mov-
ing to the right the joystick J5 on the radio
control (Picture 8).
Place the couple of ramps (of adequate di-
mensions) and bring them in correspondence
of the machine tracks.
Check that the slope approach angle
does not exceed 17° (31%) and that those
are perfectly clean from grease, mud, snow
or ice.
WARNING! If you get the machine on a
truck, go up the ramp keeping the drive
wheels on the back in order to increase
the motricity. Use loading ramps with
suitable dimensions and strength. Secure
the machine to the truck plane by cou-
plings on the chassis. Ensure that the
machine is switched off during the
transport.
1. Switch on the MEWP engine.
2. Use the radio control.
3. Check that the ramp attack is not higher
than 31° (60%) to avoid damage to car-
pentry and that the soil is perfectly clean
from grease, mud, snow or ice.
4. Travel and climb with the MEWP set as
shown below: the basket shall always be
placed at the rear of the machine.
