MAN.234 Rev.6 ENG - Use and maintenance manual S19HD page 37 of 126
In order to favor machine loading/unloading through
ramp, with the MEWP in transport position, even if it
is not stabilized, you can press the parking button P
(Picture 8) to:
o lift/lower the jib;
o rotate and level the basket;
o return the booms on their support.
4.3.2 "Self- loading” function
In order to facilitate machine self-
loading, it is advisable to remove the sta-
bilizer extensions (if any). At the end of
loading, the extensions must be included in
the closing configuration, and only then the
MEWP can be used.
• Drive and block the truck or the trailer in the
position chosen for MEWP loading.
• Perform stabilization of the S19HD using the
procedure defined in paragraph 4.4.2.
• Drive the truck, bringing it from position 1 to
position 2;
In order to avoid the overturning of the
MEWP, use the roll-over control lever 9 (Pic-
ture 8), present on radio control station: it
