MAN.234 Rev.6 ENG - Use and maintenance manual S19HD page 38 of 126
moves front or rear outriggers closer to the
ground.
Do not use the outriggers to lift the truck.
Stabilizer cylinders could damage irre-
deemably.
• Carry out the destabilization of the S19HD
using the procedure defined in paragraph
4.4.6 in order to obtain the configuration 3;
• Secure the MEWP to the truck, using cou-
plings on the frame and on outriggers.
4.3.3 Travel
The machine, thanks to a variable flow engine, has
three levels of speed identified by three different
symbols:
o "turtle": minimum speed;
o "hare": average speed;
o "double hare": maximum speed.
Check that no one is in proximity and
that the MEWP is in transport configura-
tion.
The tracks should remain extended to max-
imum width for improved stability and in-
creased ground clearance when traveling
with the MEWP. The exception is when trav-
eling through a narrow passage, the tracks
may need to be retracted to decrease the
overall width of the MEWP. It is recommend-
ed that the tracks be extended again as soon
as possible.
Check that the travel slope does not ex-
ceed the maximum longitudinal limit of
17° (31%) and the maximum transversal
limit of 10° (18%). Check that the soil is
clean from grease, mud, snow or ice.
WARNING! The hydraulic system for the
maximum speed (“double hare”) activa-
tion is a serial system. Therefore, it may
be necessary to intervene with manual
corrections during handling. Be very
careful to travel with maximum speed!
During travel, if necessary, the parking
button P allows to lift the boom in order
