MAN.234 Rev.6 ENG - Use and maintenance manual S19HD page 40 of 126
radio control station.
WARNING! The S19HD machine can
travel on a maximum inclination of 17°
(31%), using the radio control.
During travels, when reaching a 14° slope longitudi-
nally and a 7° slope transversally (pre-alarm thresh-
olds), an intermittent acoustic warning will activate;
it becomes a fixed acoustic signal at 17° longitudi-
nally or at 10° transversally (maximum alarm limits),
in order to indicate the PROHIBITION TO KEEP ON
INCREASING INCLINATION FURTHER.
If the operator continues, reaching max allowed
levels, the machine will inevitably go into total
block.
Procedure for bypass of travel block:
It is possible to bypass this block ONLY THROUGH
OPERATIONS UNDER THE FULL
RESPONSIBILITY OF THE USER, who can pro-
ceed as below:
1. move upward the lever 7 (Picture 17), placed
on the left downside of the radio control;
2. travel the machine using joysticks J1 and J6
(Picture 17).
The bypass, at this point, will be active and the op-
erator will be able to take the machine back to the
conditions prior to the block (travel in the original
direction), until stopping the previously activated
acoustic warning.
C.M.C. DECLINES ANY TYPE OF
RESPONSIBILITY TO THE OPERATOR. THE
MANUFACTURER HAS CLEARLY ESTABLISHED
TWO ACOUSTIC WARNING THRESHOLDS, IN
ORDER TO FULLY INFORM THE USER ABOUT
THE DANGERS DUE TO THE NON-
RECOMMENDED ACHIEVEMENT OF TRAVEL
SLOPE LIMIT.
4.4 MEWP use procedures
The machine is equipped with the "SCS System"
(Self Control System) which allows:
• automatic stabilization,
• automatic speed control,
• automatic closing of the aerial part.
The following procedures must be scru-
pulously and chronologically respected.
