MAN.234 Rev.6 ENG - Use and maintenance manual S19HD page 45 of 126
4.4.5 Use of the aerial part
14. After making sure the aerial part consent
light 7 (Picture 4) is on, execute the ma-
noeuvres of the MEWP aerial part using the
manipulators of the wired remote control sta-
tion or the radio control station described in
the paragraph 3.2.1.
First lift the boom, in order to rise it from
the support.
It is strictly forbidden to rotate the turret
as first movement, since it could serious-
ly damage the machine carpentry.
It is forbidden to enter or exit the work
platform at different levels, when the ma-
chine is developed.
It is forbidden to increase the outreach or
working height of the MEWP by using ad-
ditional equipment.
It is forbidden to use the MEWP as a lift-
ing device.
Avoid contact of the aerial part with fixed
objects (buildings, etc.) or with moving
objects (vehicles, lifting equipment, etc.).
4.4.5.1 Moment limiter
Thanks to a moment limiting device (anti-
tipping device fitted as standard on these
machines), all operations bringing the
machine out the working diagram are in-
effective.
When the maximum allowable outreach is almost
reached (90%), the pre-alarm indicator 7 lights up
(Picture 9).
When the maximum allowable outreach is reached
(see the working diagram in Picture 2), the alarm
indicator 15 lights up (Picture 9).
