MAN.234 Rev.6 ENG - Use and maintenance manual S19HD page 54 of 126
terclockwise rotation and downward for clockwise
rotation.
Picture 24: valve cursor for basket centering.
While return the MEWP in rest configura-
tion, the deceleration ramps of the ma-
neuver speeds will be inactive: therefore,
pay particular attention to the operations
wearing all personal protection equip-
ment provided by law.
At the end of aerial part recovery, it is
possible to get the operators off the bas-
ket.
Recovery of the outriggers and the tracks:
1. Turn the manual pump tap (Picture 25) on the
position represented by the outriggers symbol
(fully to the right).
