CMC S28 - Platform control stations

MAN.243 Rev.5 ENG - Use and maintenance manual S28 page 20 of 138
To switch off the endothermic engine, you can
alternatively:
• turn the key all the way to the left on position 0;
• lift the lever in Picture 7, if the radio control has
been used;
• press the endothermic engine start/stop button 9
again (Picture 11), if you are at the control station
in the basket;
• press, in emergency situations, one of the
emergency buttons on the machine (par. 4.6.1).
3.1.2 Switching on/off the electric motor
(*optional)
If you choose to use the electric motor (*optional):
• connect the 110/120/230 V socket (Picture 7a) to
the nearest electrical source;
Picture 7a: socket connection.
• from the radio control, start the engine by pushing
the lever in Picture 6 downwards or alternatively
from the console in the basket press the start button
of the electric motor 10 (Picture 11);
• the power supply is signaled by the lighting up of
the green led 5 both on the engine ignition station
and on the control stations.
To switch off the electric motor, it will be enough to
alternatively:
• turn the key all the way to the left on position 0;
• lower the lever mentioned above (Picture 6) of the
radio control;
