MAN.243 Rev.5 ENG - Use and maintenance manual S28 page 50 of 138
In order to avoid the overturning of the MEWP, use
the roll-over control lever 9 (Picture 16), present
on radio control station: it moves front or rear
outriggers closer to the ground.
Do not use the outriggers to lift the transport
truck. Stabilizer cylinders could damage
irredeemably.
• carry out destabilization by the procedure
described in par. 4.4.6 until the configuration 3
is obtained;
• fix the MEWP to the truck, using the appropriate
coupling on the chassis (Picture 41).
4.3.3 Travel
The machine, thanks to a variable flow motor, has three
levels of speed identified by three different symbols:
o "turtle": minimum speed;
o "hare": average speed;
o "double hare": maximum speed.
Check that no one is in proximity.
The tracks should remain extended to maximum
width for improved stability and increased ground
clearance when traveling with the MEWP. The
exception is when traveling through a narrow
passage, the tracks may need to be retracted to
decrease the overall width of the MEWP. It is
recommended that the tracks be extended again
as soon as possible. To extract the tracks, see
par. 3.2.1.
WARNING! The hydraulic system through
which the triple speed is activated (“double
hare”) is a serial system. Therefore, it may be
necessary to intervene with manual
