MAN.243 Rev.5 ENG - Use and maintenance manual S28 page 51 of 138
corrections during handling. Be very careful
to travel with triple speed!
Travel operations shall be made with the MEWP set as
shown in Picture 42: the basket shall always be placed
at the rear of the machine.
4.3.3.1 Travel using radio control
Picture 43: speed selector on travel radio control.
In order to perform a travel, using the radio control:
1. make sure all outriggers are raised off the
ground;
2. make sure the basket lock pin is inserted
(Picture 50);
3. make sure the two boom groups are returned
and supported;
4. turn on the machine (par. 3.1);
5. use the joysticks (Picture 16) to drive the tracks;
6. Position the speed selector SVR (Picture 43) of
radio control on "turtle" symbol; move it to
“hare” symbol to increase the speed of the
tracks or to “double hare” to reach the maximum
speed.
Check that the travel slope does not exceed the
maximum longitudinal limit of 19° - 34% (pre-
alarm at 17° - 31%) and the maximum
transversal limit of 8° - 14% (pre-alarm at 6° -
11%). Check that the soil is clean from grease,
mud, snow or ice.
Prefer to use the radio control for travel
operations.
