Coaire SCROLL CSOF-M3PL/H12 - Controller Functions; Status Display Ramp

25
CONTROL
 NOTE
1) ON : illuminated continuously
2) SF : slow flash on/off once per second
3) FF : fast flash on/off five times per second
4) IF : Intermittent Flash on/off every four seconds
5) OFF : Extinguished continuously
STATUS LED Green Display working status along ON / OFF
FAULT, ALARM LED Red Display fault or alarm status along ON / OFF
Machine
state Number
Machine state Status( Green ) Fault ( Red )
00 Initialization OFF
Normal: OFF
Trip: FF
Alarm: SF
Maintenance: IF
Start Inhibit: IF
01
Start Inhibit
Check
OFF
02 Ready to Start OFF
03 Start Delay
IF
if load request : FF
04 Standby IF
06
Start Motor in
star Delta
IF
if load request : FF
07 Load Delay
IF
if load request : FF
08 Load ON
09 Reload Delay
IF
if load request : FF
10 Auto stop delay IF
11
Manual stop
delay
SF
99 Shut down OFF
7-3-1 Status Display Ramp
