26
CONTROL
7-3-3 Equipment Status Display
SYSTEM LOCKED SYMBOL
7-3-4 System Locked
1. START/STOP REQUEST SOURCE DISPLAY
LOC : Controller keyboard
NET : Communication request
REM : Digital inputs
2. LOAD REQUEST SOURCE DISPLAY
PRE : Pressure sensor
NET : Communication request (Option)
REM : Digital inputs
3. STOP STATUS DISPLAY
Display while compressor stopped.
LOC STP : Stopped by controller keyboard
REM STP : Stopped by digital inputs
NET STP : Stopped by communication request (Option)
S.D STP : Stopped by fault condition
4. START STATUS DISPLAY
Display while compressor started.
LOC RUN : Started by controller keyboard
REM RUN : Started by digital inputs
NET RUN : Started by communication request (Option)
5. COMPRESSOR STATUS DISPLAY
GOOD : Normal condition
MAINTEN : Maintenance required
ALARM : Alarm condition
S-DOWN : Trip condition
INHIBIT : Start inhibit condition
