Antenna dimensions
98-145510-E Appendix A: Technical specifications A-14
Measures for antenna installation
Figure 16: EXPLORER 8100 antenna: measures for antenna installation
8.6°
334 [13.1]
343 [13.5]
As shown 171 [6.7] Rec. min. 164 [6.5] Abs. min. 148 [5.9]
Abs. max. 412 [16.2] As shown 404 [15.9]
Min. 705 [27.8]
48 [1.9]
Ø8.5
Max. 1200 [47.2]
