COBHAM EXPLORER 8100 - Page 130

OpenAMIP setup for iDirect iNFINITI & Evolution
98-145510-E Appendix C: VSAT modem settings C-6
[BEAMS]
beam_88 = E36B
maxbeam = 88
[BEAMS_LOCAL]
inhibit_tx_ifzero = 0
[BTP]
device_mode = tdma
device_name = btp
device_path = /dev
[BTP_REQ]
device_mode = tdma
device_name = btp_req
device_path = /dev
[COMPRESSION]
Threshold = 90
[DEBUG]
cpu_util_test_enabled = 0
[DVBS2]
frame_length = 125.000000
frame_size = short
mode = acm
ncr_interval = 3375000
pilot = 1
rc_roll_off = 0.200000
[ENC]
auth_level_required = 0
enc_enabled = 0
enc_layer_enabled = 0
enc_mode = 0
peer_mode = 1
[ETH0]
interface = ixp0
phy_count = 1
[ETH0_1]
address = 10.1.6.1
netmask = 255.255.255.128
(ACU LAN1 subnet setting)
rip_enabled = 0
web_server_enabled = 0
