To install the EXPLORER 8000 series
98-145510-E Chapter 3: Installation 3-5
3.2.4 Installation of the VSAT modem
For a list of supported VSAT modems see VSAT modem unit on page 2-9.
1. Mount the VSAT modem close to the ACU, preferably at a distance less than 1 m.
2. Connect all cables. See VSAT modem settings on page C-1 for a description of the
connectors for supported VSAT modems. For cable specifications see VSAT modem
cables on page B-1.
3.2.5 To connect the ACU, VSAT modem and antenna pedestal
The connections to be made depend on the VSAT system (Ku or Ka) and the VSAT modem
used. The drawings on the next pages show an overview of connections in an
EXPLORER 8000 series Ku system and an EXPLORER 8000 series Ka system.
• For details on how to connect the modem, see VSAT modem settings on page C-1.
• For details on the interfaces, see Interfaces on page 4-1.
