The web interface
98-145510-E Chapter 6: Setup and operation 6-8
Setting Values Explanation
Predefined satellites User defined data or
selection of satellites
Select a satellite from the list, or select
User defined data and enter all
information manually.
Use reference satellite Checkbox Select Use reference satellite if you
are going to use a reference satellite. See
To use a reference satellite (Ku only) on
page 6-9.
Satellite position degrees E or W Position of the satellite
Polarisation skew degrees See documents from VSAT provider
Maximum inclination degrees Sets the satellite search window size to
match inclined orbit satellites.
Elevation cutoffl degrees The minimum elevation angle for the
antenna to function. According to FCC
(FCC §25.205) regulations the Elevation
cutoff must be minimum 5 degrees.
RX polarisation Horizontal or vertical Polarization of the desired RX signal
TX polarisation X-pol or empty Polarization of the TX signal - relative to
the desired RX signal. Orthogonal (X-pol)
or same (Co-pol).
RX IF frequency MHz RX IF frequency from the VSAT modem
LNB LO frequency 9.75 or 10.75 GHz Select 9.75 if the RX frequency is
between 10.7 GHz and11.7 GHZ
Select 10.75 if the RX frequency is
between 11.7 GHz and 12.75 GHZ
RX RF frequency GHz Receiving frequency
TX RF frequency GHz Transmitting frequency
Tracking type Narrow band,
VSAT modem RSSI,
DVB-S/DVB-S2 or
Wideband power
Select which signal should be used for
tracking.
RX frequency Modem or User
defined
Select Modem to use the modem RX
frequency or select User defined and
enter the RX frequency manually.
Table 6-4: Settings for satellite profile
