Keypad and display menus
98-145510-E Chapter 6: Setup and operation 6-31
PROFILE Description
<PROFILE> Lists the available satellite profiles. Use and to go through the
profiles and press OK to select the profile you want to activate.
Table 6-20: PROFILE menu
ANTENNA Description
POINTING ANTENNA STATE: Current state of the antenna, e.g. TRACKING
ELEVATION: Current elevation angle of the antenna
AZIMUTH: Current azimuth of the antenna, with reference to North
POLARIZATION RX POLARIZATION: HORIZONTAL, VERTICAL, (LEFT or RIGHT)
TX POLARIZATION: HORIZONTAL, VERTICAL, (LEFT or RIGHT)
GPS LATITUDE: current latitude, read from GNSS module
LONGITUDE: current longitude, read from GNSS module
FIX TYPE: 2D or 3D or USER (USER means the position is entered
manually)
HEADING Orientation of the mounting base in relation to estimated North.
VERSIONS Current software version of the antenna
SERIAL NUMBERS Serial numbers of the antenna and the ACU
Table 6-21: ANTENNA menu
MODEM Description
MODEM TYPE Current modem type.
TX ENABLE On or off, information delivered by the connected VSAT modem.
RX LOCK On or off, information delivered by the connected VSAT modem.
SIGNAL LEVEL Current input signal level from the VSAT modem, in dB.
Table 6-22: MODEM menu
NETWORK Description
PORT 1 IP Current IP address for LAN1 (service port)
PORT 1 MASK Current netmask for LAN1
PORT 2 IP Current IP address for LAN2 (modem port)
PORT 2 MASK Current netmask for LAN2 (modem port)
PORT 3 IP Current IP address for LAN3
Table 6-23: NETWORK menu
