Keypad and display menus
98-145510-E Chapter 6: Setup and operation 6-32
Example: EVENT 1/4*: This is the first event out of a list of 4 and there has been a
change in the list. EVENT 1/4 will always be shown, the * indicates a change.
PORT 3 MASK Current netmask for LAN3
PORT 4 IP Current IP address for LAN4
PORT 4 MASK Current netmask for LAN4
PORT 5 IP Current IP address for LAN5
PORT 5 MASK Current netmask for LAN5
DEFAULT GATEWAY Current default gateway
SATELLITE Description
POSITION Current satellite position
RX POLARIZATION
a
a. Only for Ku antenna
-, HORIZONTAL, VERTICAL, (LEFT or RIGHT)
TX POLARIZATION
a
-, HORIZONTAL, VERTICAL, (LEFT or RIGHT)
RX FREQUENCY
a
Current RX frequency
LNB LO
a
LNB LO frequency
TX FREQUENCY
a
Current TX frequency
BUC LO
a
BUC LO frequency
Table 6-24: SATELLITE menu
EVENT Description
<EVENT> In this menu all active events are listed. Use and to go through the
active events.
Events can be of the type WARNING or ERROR.
If a new event occurs or there is a change in the event list while you are in
the EVENTS menu, a * is shown in the upper left corner of the display, next
to the menu name. Press OK to update the EVENTS list, the * will be
removed.
A > means the event text is longer than the display. Press > to see the
remaining text.
Table 6-25: EVENTS menu
NETWORK Description
Table 6-23: NETWORK menu (Continued)
