1-2
Chapter 1: General information 98-144591-D
Technical data
User-programmable
channels: 199 frequency pairs with mode (1-199)
User-programmable
stations: 40 stations with name, MMSI and station channel
Supply voltage: Nominal 24V DC (-10 +30% — 21.6 - 31.2 V DC)
With optional external AC power supply:
115/230V AC 50/60 Hz. Automatic change-over to DC in the absence of AC supply
Power consumption:
Rx Mode: Approximately
45W
150 W 250 W 500 W
Tx, SSB speech 175 W 300 W 600 W
Tx, SSB two-tone 300 W 550 W 1100 W
Tx, DSC/TELEX 310 W 600 W 1000 W
Compass safe distance:
Compass safe distance in accordance with ISO/R 694 are given below in metres
Unit
Standard
5.4°/H
Steering
18°/H
Control Unit 1.2 0.5
Transceiver Unit 0.85 0.25
Antenna Tuning Unit 0.6 0.3
Handset 0.3 0.2
Cradle 1.1 0.7
Loudspeaker 2.2 1.6
IP ratings (estimated):
System Transceiver Unit
Antenna Tuner
Unit *
Control Unit
150 W IP43 IP56 IP54
250 W IP43 IP56 IP54
500 W IP20 IP56 IP54
* Antenna cable must be carefl ly installed to obtain this IP rating
Dissipated heat: The dissipated heat in standby RX mode is typically 45 W depending on
attached ancillary equipment.
In transmit mode, use the consumption fi gures for the appropriate mode,
multiplied by 0.66.
E.g. 0.66 x 175 W = 115.5 W dissipated heat for a 150 W system in SSB
speech mode.
For a fi gure in kilocalories (kcal), multiply dissipation effect by on-time in
hours and then by 0.860.
For the 150W system, e.g. 115.5 W x 2 h + 45 W x 22 h (TX 2 hours + RX
22 hours a day) = 1221 Wh. 1221 Wh x 0.860 ~ 1050 kcal a day.
