Chapter 5: Spare part exchange5-8 98-144591-D
5.5 Required service tools
150 W/250 W
For disassembling transceiver unit: Slotted screwdriver
For shield cover, print and cables: Torx screwdriver T10
500 W
For disassembling transceiver unit: Hexagonal socket wrench 1/4" lenght min.16 cm
For transceiver modules and cables: Torx screwdriver T10
Slottet screwdriver
Spanner for M5 nut
5.6 Accessory list
Item Part no.
SAILOR 6301 Control Unit Class A 406301A-00500
SAILOR 6365B 150 W MF/HF Transceiver Unit DSC Class A 406365B
SAILOR 6366B 150 W MF/HF Transceiver Unit DSC Class A FCC 406366B
SAILOR 6368B 250 W MF/HF Transceiver Unit DSC Class A 406368B
SAILOR 6369B 500 W MF/HF Transceiver Unit DSC Class A 406369B
SAILOR 6381 150 W/250 W Antenna Tuning Unit DSC Class A 406381A
SAILOR 6383 500 W Antenna Tuning Unit DSC Class A 406383A
SAILOR 6384B 500 W Antenna Tuning Unit DSC Class A 406384B
SAILOR 6018 Massage Terminal 406018A-00500
SAILOR 6006 Massage Terminal 406006A-00500
SAILOR 6001 Keyboard for Message Terminal 406001A-00500
SAILOR 6103 Multi Alarm Panel 406103A-00500
SAILOR 6080 Power Supply 406080A-00500
SAILOR 6081 Power Supply & Charger 406081A-00500
SAILOR 6197 Ethernet Switch 406197A-00500
SAILOR 6208 Control Unit Connection Box 406208A
SAILOR 6209 Accessory Connection Box 406209A
SAILOR 6270 External 8W Loudspeaker 406270A
SAILOR 6588 DGNSS Receiver 406588A-00500
SAILOR 6286 DGNSS Antenna - Active 406286A-00500
Optional installation kit (3 x SAILOR 6080 + 1 x SAILOR 6081) 406081-004
ATU Mounting Kit
Mounting plate and fi ttings for mast 737589
Mounting plate 737588
Gasket kit for Antenna Tuning Unit 737822
Accessory list
