2-32
Chapter 2: Installation
98-144591-D
Confi guration
2.11 Confi guration
The GMDSS approved radio is by default confi gured to meet the legislative requirements and restrictions.
Optional functionality may be confi gured and will normally require national exemptions to be utilized.
Confi guration and test facilities, which are considered ‘user facilities and basic settings’, are available
via the menu structure.
Further confi guration possibilities are available behind the access password >1-2-3-4-5< indicating that
any changes in this area will affect the system operation and therefore should be done with caution.
Other confi gurations considered installation features are accessed via the Service Interface.
Please refer to the '97-147768 – User manual SAILOR 6000B MF/HF Service Interface', available for
download at Cobham extranet.
2.11.1 CU confi guration
Priority setting is via the menu and Main CU is High Priority = ON and Slave CU is High Priority = OFF.
Operation Key Operation Function
Press 2 2 x More
2 Setup
2 3 x > Controller Setup
Scroll down to 11 Rotate High Priority
Select 11 Press
Select 11 Rotate High Priority = ON/OFF
Press 2 Exit To store
2.11.2 ATU confi guration
ATU is default enabled.
ATU enable/disable is confi gured via the Service Interface.
Only disable ATU when testing on 50 load or using a dedicated antenna matched for a certain frequency.
2.11.3 DSC printing ON/OFF
Operation Key Operation Function
Press 2 2 x More
2 Setup
2 3 x > DSC Setup
Scroll down to 11 Rotate Print DSC: OFF
Select 11 Press
Select 11 Select ON/OFF
LAN connected printer can now be selected to print DSC messages from the log. A SAILOR 6004 Control
Panel with printer is also accepted. Please check ‘2.12.4 DSC Printer Confi guration’ for setup.
