2-24
Chapter 2: Installation
98-144591-D
Interconnection of units
Cable 11: Message Terminal
Cable: Shielded high quality USB-cable
Maximum cable length 1 m
Cable 12: Ethernet
Cable: STP/FTP CAT-5E or better
Maximum cable length 100 m
Cable 13: Transceiver Unit – 24 V Battery
For power cable information see section 2.6 DC Power Cabling
Cable 14: Message terminal
Cable: 5 x LTW-UL2464 24AWG
5 m cable supplied with Telex option kit
Message
terminal
Designation Remarks Color
SAILOR 6208
Control Unit
Connecton Box
'NMEA'
5 way LTW
Pin number
1 System GND GND 1
2 CAN S CAN Vcc Red 4
3 CAN C
CAN GND
Black 7
4 CAN H CAN H White 5
5 CAN L CAN L Blue 6
Cable 15: Control Unit - Transceiver Unit
Maximum cable length 100 m
For extended cable length, use shielded twisted pair cable 6x2x0.5mm
2
(AWG 20) or better
For connection details refer to wiring table for cable 3.
