Adjustments
HF SSB Transceiver 9323/9360/9390/9780 Technical Service Manual 7-7
Test channels for 2.0 to 26.5 MHz PA assembly
Table 7 -5: Test channels for 2.0 to 26.5 MHz PA assembly
108-04963
Channel Frequency
MHz
PA LPF
range
Receiver
HPF
RF Amp Talk
Power
Select
Remarks
1 2.0 2.0-3.1 2.0-3.1 On Off
2 2.5
3 3.0
4 3.1 3.1-4.8 3.1-4.8 On Off
5 3.5
6 4.7
7 4.8 4.8-7.47 4.8-7.47 On Off
8 5.5
9 7.4
10 7.5 7.47-11.6 7.47-11.6 On Off
11 8.5
12 11.5
13 11.6 11.6-18.0 11.6-18.0 On Off
14 15.5
15 17.9
16 18.0 18.0-27.0 18.0-27.0 On Off
17 22.0
18 26.5
19 27.0
20 2.0 2.0-3.1 2.0-3.1 Off On See Note
40 19.999 18.0-27.0 18.0-27.0 On Off 90-20523-XXX
41 20.001 Ver 4.2 onwards
©
Channel 20 (2.0 MHz) checks the transmit power with talk power on. Also the
receiver sensitivity can be measured with the RF amplifier off. All remaining
channels (1 to 19) have the talk power off. This allows the two-tone transmit
signal to be viewed on the oscilloscope without the ripple being displayed.
