5.2 Flush Mount IP1501 Series
IP1500FlushMount:4.00”wx5.00”h
5.00
5.00
2.16
.58
1.47
1.72
3/4" Conduit Thread
BottomView
IP1500Faceplate-BacksideGrounding IP1501BaseFaceplate-BacksideGrounding
Groundlugwillbeplacedonastudwithbaremetalononesideandakepnutholdingitinplace.
Thelugusedforthe1500requiresa#6eyelettypelug.
