5.4 Flush Mount IP2501 Series
IP2501SeriesFlushMount:9.00”wx9.00”h
9.00
9.00
3.60
4.13
1.75
.88
9.00
9.00
3.60
4.13
1.75
.88
BackView BottomView
IP2500SeriesFaceplate-BacksideGrounding IP2501SeriesBaseFaceplate-BacksideGrounding
Groundlugwillbeplacedonastudwithbaremetalononesideandakepnutholdingitinplace.Thelug
usedforthe2500requiresa#6eyelettypelug.
