IP1500 and IP2500 Series
Administrator Guide
Special Warning: High Voltage – Range 37 - 57V DC <12.96 watts (27mA)
Grounding
TheIP2500seriesisUL2017safetyrated.DuetothestandardPoE802.3afpowersuppliedbythe
remote(IEEE802.3afor“at”rated)PoESwitch,theIP2500hasaprotectiveearthingterminalcable
available.Theremustbeanuninterruptiblesafetyearthgroundattachedtothegroundinglanyard
provided.Wheneveritislikelythattheprotectionhasbeenimpaired,disconnecttheEthernetcable
untilthegroundhasbeenrestored.Thisisanon-emergency,non-monitoredproductline.
GroundterminationspointshavebeenmarkedinaccordancewithUL2017standards.Approved
iconshavebeenappliedtoindicationthegroundinglocation.
Ground Wire Connection
Locatethe18ggreengroundwire,whichisterminatedwitharinglugthathasbeensecuredtoa
faceplatestud.Thelooseendofthegreengroundwiremustbesecuredtoanearthgroundnearby.
Iftheenclosurehasmarkedgroundinglocation,andagreengroundingscrewisavailable,please
useitwheneverlocalcodesdictateearthgroundisrequired.Groundterminationlocationscanbe
labelledusingthefollowinggraphicsymbol:
Ground Images sample:
Therearenouser-serviceablepartsinsidetheseproducts.Anyservicing,adjustment,maintenance
orrepairmustbeperformedonlybyservice-trainedpersonnel.Theseproductsdonothaveapower
switch;theyarepoweredonwhentheEthernetPoEcableispluggedin.
ELECTRICAL SAFETY WARNINGS
Thisdeviceissuitableforuseinnon-hazardouslocationsonly.
WARNING:ExplosionHazard–Donotreplacethedeviceunlesspowerhasbeenswitchedoffor
 theareaisknowntobenon-hazardous.
WARNING: Donotoperatetheequipmentinthepresenceofammablegassesorfumes.Operating
 electricalequipmentinsuchanenvironmentconstitutesadenitesafetyhazard.
WARNING: IftheequipmentisusedinamannernotspeciedbyCodeBlueCorp.,theprotection
 providedbytheequipmentmaybeimpaired.
WARNING: Donotperformanyservicesontheunitunlessqualiedtodoso.Donotsubstitute
 unauthorizedpartsormakeunauthorizedmodicationstotheunit.
WARNING: Properlygroundtheunitbeforeconnectinganythingelse.Unitsnotproperlygrounded
 mayresultinasafetyriskandcouldbehazardousandmayvoidthewarranty.Seethe
 groundingtechniquesectionforproperwaystogroundtheunit.
WARNING: Donotoperatetheequipmentinamannernotspeciedbythismanual.
WARNING: Donotworkonequipmentorcablesduringperiodsoflightningactivity.
WARNING: InstallonlyinaccordancewithLocal&NationalCodesofAuthoritiesHaving
Jurisdiction. (Revised2010-11-15)5
