Coffee Queen CQube MF13 - Interior of Cqube LF13

CQube MF & LF
10
OVERVIEW OF COMPONENTS
Interior of CQube LF13
Ingredient canisters of CQube LF13
Bean Hopper
Ingredient Canisters
Grinder
Brewing Mechanism
Mixing Bowl
Drink Outlet
Waste Box
DETAIL INGREDIENTS WIDTH DEPTH HEIGHT CAPACITY CUPS/UNIT
Hopper Beans ---- ---- ---- 4.0kg ~360 Cups
Canister Espresso 67mm 180mm 400mm 0.66kg ~300 Cups
Canister Chocolate 67mm 180mm 400mm 2.66kg ~120 Cups
Canister Topping 67mm 180mm 400mm 1.95kg ~180 Cups
