17
CQube MF & LF
B
INSTALLATION AND START-UP
Fill ingredient canister and bean hopper
Lift the lid and  ll the bean hopper with freshly
roasted coffee beans without additives.
Remove the ingredient canisters to avoid spilling
in the machine and  ll with ingredients.
When  lling the ingredients, keep the opening of
the canister chute upwards (A).
Reassembly canisters.
When placing the ingredient canisters, Ensure that
the openings of the canister chutes point down
toward the mixing bowl (C).
01
03
05
02
04
Open the bean stop (B) on the bean hopper.
The machine is ready to use.
A
C
