17. TROUBLESHOOTING
Issues of Improper Operation Belt Burning
Possible Causes Solutions
Loading the ATV into a
pickup or tall trailer when in
high range.
Shift transmission to Low Range during
loading of the ATV to prevent belt burning
Starting out going up a
steep incline
When starting out on an incline, use low
range, or dismount the ATV after first
applying the park brake and perform the “K”
turn as described in this manual.
Driving at low RPM or low
ground speed (at
approximately 3-7MPH/
5-12km/h）
Drive at higher speed or use low range. The
use of low range is highly recommended for
cooler CVT operating temperatures and
longer component life.
Insufficient warm-up of
ATV’s exposed to low
ambient temperatures.
Warm engine at least 5 min., the with
transmission in neutral, advance throttle to
approx. 1/8throttle in short bursts, 5 to 7
times. The belt will become more flexible
and prevent belt burning.
Slow and easy clutch
engagement.
Fast, effective use of the throttle for efficient
engagement.
Towing /Pushing at low
RPM/low ground aped.
Use low range only.
Stuck in mud or snow. Shift the transmission to low range carefully
use fast, aggressive throttle application to
engage clutch. WARNING: Excessive
throttle may cause loss of control and
vehicle overturn.
Climbing over large objects
from stopped position.
Shift the transmission to low range carefully
use fast, aggressive throttle application to
engage clutch. WARNING: Excessive
throttle may cause loss of control and
vehicle overturn.
101
